July 30, 2026 – BRT officially unveils the upgraded baoruitong Hydrostatic Pressure Test System, a modular, IoT-enabled testing solution tailored for accurate long-term and short-term hydrostatic pressure testing of plastic pipes, fittings, fibre glass vessels, tubes and hoses. Designed to empower Industry 4.0 and smart manufacturing workflows, the new-generation system delivers high-precision testing, cloud-based intelligent control and full international standard compliance, catering to R&D and mass production testing demands across the plumbing, construction and industrial fluid conveyance industries.

Engineered for versatile material compatibility, the baoruitong test system supports testing for diverse materials including PE, PEX, PVC, PP, PB and glass fibre. It fully complies with global authoritative testing standards coveringISO 1167, EN 12293, ASTM D1598 and ASTM D1599, ensuring consistent, reliable and certifiable test results for global market access.

Smart Cloud Control for Simplified, Efficient Testing Operations

Setting a new benchmark in user-centric testing, the baoruitong system is powered by cloud-based baoruitong software, delivering stable, linear pressure regulation and intelligent full-process control. The multi-terminal compatible interface supports operation via PC, smartphones and iPads (optimized for iPad), enabling ultra-efficient test management with just three clicks to start tests.

The integrated smart recipe system allows fast parameter setup and one-click reuse of saved test schemes, drastically cutting preparation time for repeated tests and tests for pipe fittings of different diameters. Equipped with automatic calibration, instant report generation and dynamic real-time finish time adjustment functions, the system minimizes manual intervention and human error. To adapt to industrial intelligent upgrading, it supports OPC UA industrial connectivity, wide-range SQL database compatibility and complies with the Cyber Resilience Act (CRA), laying a solid foundation for enterprise digital transformation and intelligent production.

In addition, the system adopts hierarchical user permission management, with four user levels from Basic to Advanced. It supports simultaneous full-process monitoring and view-only access for partners and clients, realizing transparent and collaborative test management for enterprise teams and cooperative clients.

Fully Modular Design for Flexible, Scalable Testing Solutions

The baoruitong Hydrostatic Pressure Test System features a fully modular architecture, consisting of a central PowerPack pressure supply unit and multiple interchangeable pressure modules. The flexible configuration supports customized testing demands, suitable for small laboratory R&D, batch production inspection and large-scale industrial testing scenarios, with expandable stations up to 50 pressure outlets per cabinet.

The core PowerPack central supply unit adopts high-performance pumps and 10-micron inlet filters, featuring energy efficiency, stability and long service life. It provides a maximum regulated pressure output of 100/160 bar (1450–2320 psi) and an optional unregulated pressure output up to 200 bar (2900 psi), with a maximum flow rate of 17 l/min, meeting diverse high-standard pressure supply demands.

Diversified Module Combinations to Cover All Testing Scenarios

To adapt to different pressure, flow and test volume requirements, BRT has configured multiple professional pressure modules for the baoruitong system, covering static, step and burst testing:

• Standard Pressure Modules: Provides 5 or 10 independent high-precision pressure stations, with a maximum pressure of 160 bar and a single-station flow rate of 2 l/min, ideal for conventional long-term and short-term pipe pressure testing.
• HCP3 High-Flow Modules: Equipped with 3 independent stations, supporting a maximum pressure of 250 bar and a high flow rate of 15 l/min, perfectly suited for large-volume and high-flow test scenarios.
• HP3/HP5 High-Pressure Modules: Features 3 or 5 independent high-pressure stations with a maximum pressure of 250 bar and a single-station flow of 2 l/min, delivering precise and stable high-pressure testing for special pipe materials.

Cost-Effective liteSERIES Solutions for Small-Scale Laboratories

For small laboratories and small-diameter pipe and fitting testing scenarios, BRT launches the lightweight liteSERIES independent testers, including burstONE, liteFIVE and baoruitonglite models, with plug-and-play installation and low maintenance costs. Matched with the 350L liteTANK (temperature range 0–95°C, temperature control accuracy ±0.5°C, support for chiller connection), it forms a complete compact testing solution.

Among them, liteFIVE supports 100 bar pressure and 2 l/min flow; baoruitonglite reaches 160 bar pressure with a maximum flow of 8 l/min; burstONE is dedicated to burst and short-term failure tests, with a maximum pressure of 200 bar and 15 l/min high flow. All liteSERIES products fully comply with ISO 1167, ASTM D1598 and ASTM D1599 standards.

Complete Supporting Equipment & Global Standard Compliance

BRT provides full-set supporting equipment for the baoruitong system, including 0–95°C constant-temperature thermo test tanks, tie-bar and non-tie-bar end closures (Model 1530, 1550, 1520), realizing one-stop pipe pressure test solutions. Strictly verified to meet ISO 1167, ISO 9080, EN 12293, ASTM D1598 and ASTM D1599 international standards, the system guarantees test data authority and global applicability.

Combining modular flexibility, intelligent digital control and high-precision testing performance, the BRT baoruitong Hydrostatic Pressure Test System helps manufacturing and testing enterprises upgrade their testing processes, improve test efficiency and accuracy, and seize advantages in the era of Industry 4.0 intelligent manufacturing.

About BRT

BRT is a professional global provider of pipe testing equipment and intelligent testing solutions, focusing on the R&D, production and customization of high-precision pressure testing, temperature testing and material performance testing equipment. Committed to helping enterprises achieve standardized, intelligent and efficient product quality testing, BRT’s products are widely used in pipe manufacturing, material R&D, quality inspection institutions and industrial manufacturing fields worldwide.
