Description
| Product Name | BRT-1150V UV/Vis Spectrophotometer | Type | Visible Spectrometer |
| Wavelength Range | 325 ~ 1050 nm | Wavelength Accuracy | ±1.5 nm |
| Wavelength Repeatability | ≤0.5 nm | Spectral Bandwidth | 4 nm |
| Wavelength Resolution | 0.1 nm | Transmittance Accuracy | ±0.3 %T |
| Measuring Range | 0 ~ 200%T, -0.301 ~ 3.000Abs, -9999 ~ 9999C, -9999 ~ 9999F | Optical System | Single Beam, 1200 Gratings |
| Light Source | Tungsten Lamp, Deuterium Lamp | Warranty | 1 Year |
| Customized Support | OEM | Brand Name | BRT |
| Weight | 8 kg | Place of Origin | Liaoning, China |
| Quartz Cuvette (10 mm) | 2 pcs | Glass Cuvette (10 mm) | 4 pcs |
| Dimensions | 470(W) × 345(D) × 180(H) mm | - | - |
Highlights at a glance
- LCD large-screen dot-matrix display with full Chinese menu interface, simultaneously showing T (Transmittance) and A (Absorbance).
- Wavelength display with 0.1 nm resolution ensures stable and accurate readings.
- Spacious sample chamber accommodates cuvettes ranging from 5 mm to 100 mm, supporting flexible testing requirements.
- Advanced microcomputer processing technology improves operation convenience and system efficiency.
- High-performance optical system with 1200 lines/mm grating, imported deuterium lamp, tungsten lamp, and detector ensures excellent instrument performance.
- Automatic wavelength adjustment with automatic 0A and 100% T calibration for improved accuracy and stability.
- Built-in quantitative measurement function displays spectrum and regression equation, with automatic curve saving and storage for up to 200 sets of data and standard curves.
- Photometric measurement function with direct data saving, supporting storage of up to 200 data sets.
- USB interface compatible with optional professional analysis software, enabling photometric, quantitative, and kinetic measurement functions.
- Parallel port printing supported with optional dedicated printer for measurement result output.
- Automatic wavelength calibration, lamp switching, and independent control of deuterium and tungsten lamps.
- Light-touch button interface for simple, convenient, and user-friendly operation.
Instrument Functions
- Absorbance (A): Measure the absorbance value of the sample, and the measurement result can be printed.
- Energy (E): Measure the energy value of the sample, and the amplifier gain is adjustable.
- Transmittance (T): Measure the transmittance value of the sample, and the measurement result can be printed.
- Concentration (C): Calibrate with standard samples, and the measurement result can be printed.
- Factor (F): Input coefficients K and B to measure the sample concentration, and the measurement result can be printed.
Instrument Features
- Adopting a holographic grating with 1200l/mm and low stray light, along with an optimized optical path design, ensures higher measurement accuracy of the instrument.
- The new wavelength driving mechanism greatly improves wavelength accuracy and repeatability, and effectively reduces operating noise.
- A 3.5-inch TFT color LCD screen with 480×320 pixels, featuring excellent display effects and simple operation.
- A spacious sample chamber, compatible with 5~100mm sample cell holders and other accessories.
- Membrane keys, knob encoder, automatic movement of wavelength to the set position, and automatic zero calibration.
- Mode A: Absorbance; Mode T: Transmittance; Mode F: Energy; Mode C: Establish the equation C=KA+B.
- It can be connected to a personal computer via USB, and the instrument can be controlled remotely through software, enabling advanced functions such as full-wavelength scanning, kinetics, and multi-wavelength.
Shenyang Baoruitong Automation Equipment Co., Ltd. was founded in 2012 and is located in Shenyang, Northeast China's traditional equipment manufacturing base. With a registered capital of RMB 5 million, the company specializes in the R&D, manufacturing, sales, and service of testing equipment. Our products are widely used in construction engineering, fire protection, HVAC, energy-saving,environmental protection, and water-saving fields. We have developed over ten product series with more than one hundred models, including building testing, HVAC testing, fire testing,coating testing, curtain wall and glass testing, and PVC pipe testing. With reliable and stable performance, our products remain highly competitive and are trusted by customers across various industries.
Are You a Manufacturer or a Trading Company?
Shenyang Baoruitong is a professional manufacturer of testing equipment, not a trading company. With more than ten years of experience in developing automated testing systems, we provide complete solutions covering product design, hardware development, software integration, manufacturing, installation, and after-sales service.
Our proprietary technologies achieve measurement precision of up to ±0.001 mm, while our modular engineering approach allows rapid customization to meet specific customer requirements. Certified under ISO 9001 and CE standards, our products are exported to more than 30 countries worldwide.
What Is Your Production Capacity?
Our company operates a standardized manufacturing facility covering 3,000 square meters, with an annual production capacity exceeding 500 units of testing equipment.
Supported by a dedicated R&D team of more than 20 engineers and specialists, we have successfully completed large-scale projects for the solar energy, building energy efficiency, and fire safety industries, ensuring reliable product quality and on-time delivery.
What Certifications Do Your Products Have and How Is Quality Ensured?
All product lines are manufactured under the ISO 9001 Quality Management System. Core testing equipment is CE certified and supported by independent third-party testing reports where applicable.
Our quality assurance process includes:
- 100% incoming raw material inspection
- Three-stage quality control during production
- Comprehensive performance testing before shipment
- 24-hour continuous operation testing to ensure stable performance
Is the Equipment Difficult to Operate? Is Training Required?
No. The equipment features an intuitive bilingual Chinese-English touch-screen interface with one-click testing procedures, making operation simple and user-friendly.
We provide free online and on-site training. Most users can operate the equipment independently within one to two days. Detailed user manuals, video tutorials, and remote technical assistance are also available whenever support is needed.
Are Operating Costs High? Is Maintenance Complicated?
Operating costs are low thanks to energy-efficient hardware that typically consumes around 30% less power than comparable industry equipment.
Daily maintenance is straightforward. The modular design allows quick replacement of components and consumables, while routine maintenance generally involves only basic cleaning and periodic consumable replacement.
We provide comprehensive maintenance documentation and lifetime technical support to ensure long-term equipment reliability and performance.
